Supermicro Systems Intel SSG-6027R-E1CR12N X9DRi-LN4+F, CSE-826BE1C-R920LPB
Integrated Solutions Expertise
Unrivaled Quality Assurance
24/7 Tailored Customer Support
Support Solutions
Supermicro logo
Huawei Gold Partner

Supermicro

Systems Intel SSG-6027R-E1CR12N

X9DRi-LN4+F, CSE-826BE1C-R920LPB
Loading price... (€2647.51)
€ 2647.51
Loading price...
Ships within 2-3 business days
Try before you buy
In stock
Minimaal 1 jaar Carry-in-garantie voor servers

Supermicro ID: SSG-6027R-E1CR12N

Need Assistance? Contact our experts

Available Monday to Friday, 09:00 - 17:30 hours

Start Chat
Loading: Specifications...
Specifications
Key Features
1. Dual socket R (LGA 2011) supports
    Intel® Xeon® processor E5-2600
    and E5-2600 v2 family†
2. Up to 1.5TB ECC DDR3, up to
    1866MHz; 24x DIMM slots
3. 4x PCI-E 3.0 x16, 1x PCI-E 3.0 x8,
    1x PCI-E 3.0 x8 (in x4) slots; Slots 1
    and 2 occupied by HW RAID controller
    and JBOD expansion port
4. Intel® i350 GbE Controller; 4x ports
5. 12x 3.5" Hot-swap SAS3/SATA3 HDD
    bays w/ SES2; Optional Internal bracket
    for 2x 2.5" drives (fixed mounting)
6. Hardware RAID via Broadcom 3108 controller
7. Server remote management: IPMI 2.0
    / KVM over LAN / Media over LAN
8. 3x 8cm high-performance PWM fans
9. 920W Redundant Power Supplies
    Platinum Level (94%)

Product SKUs - Discontinued SKU (EOL). Please contact sales-rep for alternative options.
SSG-6027R-E1CR12N
  • SuperServer 6027R-E1CR12N (Black)

Motherboard

Super X9DRi-LN4F+

Processor/Cache
CPU
  • Dual Socket R (LGA 2011)
  • Intel® Xeon® processor E5-2600
        and E5-2600 v2 family†
        (up to 130W TDP)
Note † BIOS version 3.0 or above is required
Cache
  • Up to 30MB
System Bus
  • QPI up to 8 GT/s

System Memory
Memory Capacity
  • 24x 240-pin DDR3 DIMM slots
  • Up to 1.5TB DDR3 ECC LRDIMM
  • Up to 768GB DDR3 ECC Registered memory (RDIMM)
  • Up to 192GB DDR3 ECC Un-Buffered memory (UDIMM)
Memory Type
  • 1866/1600/1333/1066/800MHz ECC DDR3 SDRAM 72-bit, 240-pin gold-plated DIMMs
DIMM Sizes
  • 32GB, 16GB, 8GB, 4GB, 2GB, 1GB
Memory Voltage
  • 1.5 V, 1.35 V
Error Detection
  • Corrects single-bit errors
  • Detects double-bit errors (using ECC memory)

On-Board Devices
Chipset
  • Intel® C602 Chipset
SATA
  • SATA 2.0 3Gbps with RAID 0, 1, 5, 10
  • SATA 3.0 6Gbps with RAID 0, 1, 5, 10
SAS3 AOC
  • Broadcom 3108 SAS3 AOC
  • Hardware RAID 0, 1, 5, 6, 10, 50, 60
IPMI
  • Support for Intelligent Platform Management Interface v.2.0
  • IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
  • Nuvoton WPCM450 BMC
Network Controllers
  • Intel® i350 Gigabit Ethernet
  • Virtual Machine Device Queues reduce I/O overhead
  • Supports 10BASE-T, 100BASE-TX, and 1000BASE-T, RJ45 output
  • 1x Realtek RTL8201N PHY (dedicated IPMI)
Graphics
  • Matrox G200eW

Input / Output
Serial ATA
  • 2x SATA 3.0 ports (6Gbps)
  • 8x SATA 2.0 ports (3Gbps)
SAS
  • 8x SAS3 ports (12Gbps)
LAN
  • 4x RJ45 Gigabit Ethernet LAN ports
  • 1x RJ45 Dedicated IPMI LAN port
USB
  • 9x USB 2.0 ports total
    (4x rear + 4x via header + 1x Type A)
VGA
  • 1x VGA port
Serial Port / Header
  • 1x Fast UART 16550 port / 1 Header
Chassis
Form Factor
  • 2U Rackmount
Model
  • CSE-826BE1C-R920LPB

Dimensions
Width
  • 17.2" (437mm)
Height
  • 3.5" (89mm)
Depth
  • 25.5" (648mm)
Gross Weight
  • 61 lbs (27.7 kg)
Available Colors
  • Black

Front Panel
Buttons
  • Power On/Off button
  • System Reset button
LEDs
  • Power status LED
  • Hard drive activity LED
  • 2x Network activity LEDs
  • System Overheat LED
  • Power fail LED

Expansion Slots
PCI-Express
  • 4x PCI-E 3.0 x16 slots
  • 1x PCI-E 3.0 x8 slot
  • 1x PCI-E 3.0 x8 (in x4) slot
  • Slot 1 & 2 Occupied by Hardware RAID Controller and JBOD Expansion Port

Drive Bays
Hot-swap
  • 12x 3.5" Hot-swap SAS3/SATA3 HDD bays w/ SES2
Optional
  • Internal bracket for 2x 2.5" drives (fixed)

Backplane
SAS3 Backplane: SAS3 12Gbps single expander backplane, w/ LSISAS3x28 expander, support 12x 3.5" drives, with 4x mini-SAS HD connectors, 2 for uplink and another 2 for downlink

System Cooling
Fans
  • 3x 8cm 9.5K RPM, 4-pin PWM fans

Power Supply with Power Distributor
920W high-efficiency (94%+) AC-DC Redundant power supplies with PMBus and I2C
AC Input
  • 100-240 V, 50-60 Hz, 11-4.5 Amp
DC Output
  •   4 Amp @ +5V standby
  •   75 Amp @ +12V
Certification Platinum Level Certified94%+    Platinum Certified
  [ Test Report ]

System BIOS
BIOS Type
  • 128Mb SPI Flash EEPROM with AMI BIOS
BIOS Features
  • Plug and Play (PnP)
  • APM 1.2
  • PCI 2.2
  • ACPI 1.0 / 2.0
  • USB Keyboard support
  • SMBIOS 2.3
  • UEFI

Operating Environment / Compliance
RoHS
  • RoHS Compliant
Environmental Spec.
  • Operating Temperature:
       10°C to 35°C (50°F to 95°F)
  • Non-operating Temperature:
       -40°C to 70°C (-40°F to 158°F)
  • Operating Relative Humidity:
       8% to 90% (non-condensing)
  • Non-operating Relative Humidity:
       5% to 95% (non-condensing)
